Cable powder For BTTZ DL
Product details
· Chemical Analysis
| Name | MgO | CaO | Fe2O3 | SiO2 | Al2O3 |
|---|---|---|---|---|---|
| Value | ≥93 | ≤2.5 | ≤0.8 | ≤3.0 | ≤0.5 |
· Physical Analysis
| Flow Rate(F.R) | Tap Density | ||||||
|---|---|---|---|---|---|---|---|
| ≤150 S/100g | 2.10-2.30 g/cm³ | ||||||
| Sieve Analysis (%) | |||||||
| Sieve size(mesh) | +60 | +80 | +100 | +140 | +200 | +325 | -325 |
| Sieve size(mm) | 0.425 | 0.25 | 0.18 | 0.106 | 0.075 | 0.045 | -0.045 |
| Value | 0 | 30±5 | 10±5 | 20±5 | 20±5 | 15±5 | ≤6 |
· Packing
25KG in a plastic bag with a carton or a woven bag.Special packing is available on requirement.
· Remarks
①Mainly used for BTTZ Fire-proof electric cable
②According to the BTTZ cable production process,corresponding to different products,such as good waterproofperformance,no need to bake before used;and do not have waterproof performance,need low temperature bakingbefore used.
③Magnesium Oxide is non-toxic, but with some dust .Anti-dust respirator and gloves are proposed to use duringpoeration.
④In the course of transportation and storage ,it should be stored in my position where there is no corrosive gas,clean,dry,ventilated,sunlight can not shine directly,and should not be affectde by rain and snow.
